PES Supply is an authorized distributor for ENF Solar. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. SPV545-PM10-144 Product Warranty 12 Years Power Warranty 12 Years of 90 %, 30 Years of 84.8 % Total Degradation Rate ⏳ 0.51 % Power Tolerance 0 ~ +0.5 % Maximum Power (Pmax) 545 Wp Voltage at Maximum Power (Vmpp) 42.37 V Current at Maximum Power (Impp) 12.87 A Open Circuit Voltage (Voc) 50.01 V Short Circuit Current (Isc) 13.62 A Panel Efficiency 21.12 % Maximum Power (Pmax) 410 Wp Voltage at Maximum Power (Vmpp) 39.89 V Current at Maximum Power (Impp) 10.3 A Open Circuit Voltage (Voc) 47.58 V Short Circuit Current (Isc) 10.91 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.35 %/°C Temperature Coefficient of Voc -0.275 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1133x30 mm Weight 26.5 kg Cell Size 182×91 mm Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: PERC
Power Range: 535 ~ 560 Wp
Panel Efficiency: 20.73 ~ 21.69 %
Weight: 26.5 kg
Seller: SpolarPV Technology Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-18592 |
|---|---|
| Manufacturer | ENF Solar |
| Container price | |
| Container qty | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
