GoodWe MS-US (G3) — GW6000-MS-US30, 6 kW PV String Inverter w/ EZLink 4G
The GoodWe MS G3 US Series PV string Inverter - GW6000 is a high-performance, grid-tied solar inverter designed to deliver reliable energy conversion for modern residential and small commercial solar systems. Built with advanced safety features, intelligent monitoring, and superior efficiency, this inverter is engineered to meet the demanding standards of the U.S. solar market while ensuring long-term performance and stability.
Designed for installers and system owners who prioritize reliability and smart energy management, the GoodWe MS G3 US Series PV string Inverter - GW6000 supports seamless integration with advanced monitoring solutions and delivers consistent output even in challenging grid conditions.
Type 4X (IP66), built-in optimization, AFCI & Rapid Shutdown, EZLink (IEEE 2030.5). Bluetooth commissioning; Wi-Fi/LAN monitoring; 4G connectivity included for this variant.
Technical Specifications — GW6000-MS-US30
| PV Input | |
|---|---|
| Max. input power | 9,600 W |
| Max. input voltage | 600 Vdc |
| MPPT voltage @ nominal power (240 V) | 198–500 V |
| MPPT voltage @ nominal power (208 V) | 171–500 V |
| Start-up voltage | 80 V |
| Nominal input voltage (240 V / 208 V) | 380 V / 330 V |
| Max input current / Isc per MPPT | 16 A / 23.4 A |
| MPPT trackers / Strings per MPPT | 2 / 1 |
| AC Output | |
| Nominal output power (240 V / 208 V) | 6,000 W / 5,200 W |
| Nominal apparent power (240 V / 208 V) | 6,000 VA / 5,200 VA |
| Max AC active/apparent power (240 V / 208 V) | 6,000 W / 5,200 W • 6,000 VA / 5,200 VA |
| Nominal voltage / frequency | 240 / 208 V • 60 Hz |
| Max output current | 25.0 A |
| Power factor / THD | ~1 (0.8 lead…0.8 lag) / < 3% |
| Efficiency | |
| Max / CEC (240 V / 208 V) | 97.5% / 96.5% / 96.0% |
| Protection & Safety | |
| Integrated | PV string current, insulation & residual current monitoring; reverse-polarity; anti-islanding; AC overcurrent/short-circuit/overvoltage; DC switch; AFCI; Rapid Shutdown |
| Surge protection | DC SPD Type III (Type II optional); AC SPD Type III (Type II optional) |
| General | |
| Operating / storage temp | −31~+140 °F (−35~+60 °C), derate ≥ 113 °F / −40~+158 °F |
| Humidity / altitude | 0–95% / 9,842 ft (3,000 m) |
| Cooling | Natural convection |
| Interface / comms / protocol | LED, WLAN + App / RS485, Wi-Fi + LAN + Bluetooth, 4G / Modbus-RTU (SunSpec) |
| Dimensions / Weight | 19.2 × 26.4 × 7.8 in • 51.8 lb |
| Noise / Topology / Night self-use | < 25 dB / Non-isolated / < 5 W |
| Ingress protection | Type 4X (IP66) |
| Certifications / Grid Standards | |
| Standards | UL1741 / UL1741SB / UL1741-CRD, UL1699B, CSA C22.2; IEEE 2030.5, IEEE 1547 / 1547.1-2020; California Rule 21; EMC: FCC Part 15 Class B |
Variant note — EZLink 4G
4G support is marked optional in the manual; this model listing includes the 4G connectivity with EZLink.
Overview of GoodWe MS G3 US Series PV string Inverter - GW6000
The GoodWe MS G3 US Series PV string Inverter - GW6000 is part of GoodWe’s next-generation inverter lineup, offering enhanced efficiency, intelligent grid support functions, and improved system visibility. With a compact and lightweight design, it enables easy installation while maintaining robust performance across varying load conditions.
This inverter supports high DC input capacity, allowing flexibility in solar panel configuration. Its optimized MPPT technology ensures maximum energy harvest throughout the day, making it an ideal choice for rooftops with partial shading or variable sunlight exposure.
Key Features and Technical Advantages
High Conversion Efficiency
The inverter is designed to deliver excellent conversion efficiency, minimizing energy loss during DC-to-AC conversion. This results in higher usable power output and improved overall system returns.
Advanced Safety Protection
Equipped with multiple protection mechanisms such as AFCI (Arc Fault Circuit Interruption), anti-islanding protection, and ground fault detection, the system ensures safe operation for both users and the grid.
Smart Monitoring with EZLink 4G
The GoodWe MS G3 US Series PV string Inverter w/ EZLink 4G - GW6000-MS-US30) enables real-time system monitoring through wireless connectivity. This allows users to track energy production, system health, and performance data remotely, reducing maintenance time and improving operational transparency.
Installation and Design Flexibility
The GoodWe MS G3 US Series PV string Inverter - GW6000 is engineered with installer convenience in mind. Its compact housing and simplified wiring structure reduce installation time and labor costs. The inverter supports a wide input voltage range, making it compatible with various PV module configurations.
Its fanless or low-noise cooling design enhances durability and ensures stable performance even under continuous operation. This makes it suitable for both indoor and outdoor installations.
Grid Compatibility and Performance Stability
Built to meet stringent U.S. grid interconnection standards, the inverter supports advanced grid functions such as voltage ride-through, frequency ride-through, and reactive power control. These features help maintain grid stability while maximizing solar energy utilization.
The GoodWe MS G3 US Series PV string Inverter - GW6000 adapts dynamically to grid conditions, ensuring uninterrupted power generation and compliance with evolving utility requirements.
Long-Term Reliability and Durability
Constructed using high-quality components, the inverter is designed for long-term operation under diverse environmental conditions. Its robust enclosure protects internal electronics from dust, moisture, and temperature variations, ensuring consistent performance over its lifespan.
With intelligent self-diagnostics and fault detection, potential issues are identified early, helping to minimize downtime and protect system investment.
Why Choose the GoodWe MS G3 US Series PV string Inverter - GW6000?
Choosing this inverter means investing in efficiency, safety, and smart energy control. It is well-suited for homeowners and businesses seeking dependable solar performance with advanced monitoring capabilities.
By integrating modern grid support functions and intelligent communication options, the GoodWe MS G3 US Series PV string Inverter - GW6000 supports future-ready solar installations while delivering dependable energy output today.
