Bruk-Bet PEM.WS-455 455W N-Type TOPCon Bifacial Solar Panel
Model PEM.WS-455 | N-Type TOPCon | 144 Half-Cell | Bifacial | 1500V System Voltage
Product Overview
The Bruk-Bet PEM.WS-455 is a high-performance solar panel designed for modern energy needs. This 455W N-Type TOPCon module delivers exceptional efficiency at 20.82%. Its bifacial design captures sunlight from both front and rear surfaces. The dual-glass construction ensures superior durability against harsh weather conditions. Weighing only 24.5 kg, it offers easy installation on various roof types. This solar panel is ideal for residential and commercial photovoltaic systems. It features advanced cell technology to maximize power output consistently. The half-cell structure reduces internal resistance and improves overall performance. Users benefit from enhanced low-light performance and reduced shading losses. This product represents a reliable choice for sustainable energy generation today.
Key Benefits
High Efficiency: The 20.82% module efficiency maximizes energy production per square meter.
Bifacial Design: Captures light from both sides to increase total power output significantly.
Dual-Glass Durability: The robust glass construction protects against heavy wind and snow loads.
Low Shading Loss: Half-cell technology minimizes power loss when partial shading occurs.
PID Resistance: Advanced cell process prevents power degradation induced by voltage stress.
How It Works
This Bruk-Bet solar panel converts sunlight into electricity using advanced photovoltaic cells. The N-Type TOPCon technology enhances electron mobility for better efficiency. Bifacial cells absorb direct light on the front and reflected light on the rear. This dual absorption mechanism boosts overall energy generation compared to standard panels. The half-cell configuration splits each cell to reduce internal electrical resistance. Lower resistance means less heat generation and higher power output. The dual-glass structure provides mechanical strength and protects internal components. This design ensures long-term reliability even in extreme environmental conditions. The panel operates efficiently under low-light conditions like early morning or late evening. It maintains stable performance across a wide operating temperature range from -40°C to 85°C.
Photovoltaic Conversion: Sunlight hits the N-Type cells, releasing electrons to create electrical current. This process generates direct current electricity for your power system.
Bifacial Light Capture: The rear side captures reflected light from the ground or roof surface. This additional light input increases total power output significantly.
Half-Cell Optimization: Splitting cells reduces current flow and internal heating losses. This optimization improves efficiency and reduces shading impact on performance.
Technical Specifications
| Maximum Power (Pmax) | 455 Wp |
| Module Efficiency | 20.82% |
| Voltage at Max Power (Vmpp) | 34.85 V |
| Current at Max Power (Impp) | 13.06 A |
| Open Circuit Voltage (Voc) | 41.42 V |
| Short Circuit Current (Isc) | 13.92 A |
| Cell Type | N-Type TOPCon |
| Number of Cells | 144 Half-Cells |
| Module Type | Bifacial Dual-Glass |
| Weight | 24.5 kg |
| Operating Temperature | -40°C to 85°C |
| Max System Voltage | 1500 Vdc |
| Power Tolerance | 0 to +5 W |
Certifications & Compliance
Certifications: IEC 61215, IEC 61730, CE, TUV
Inverter Compatibility: Compatible with all major string inverters
Environmental: PID Resistant, Low Shading Loss, High Mechanical Load
Warranty: 15 Year Product Warranty, 25 Year Power Warranty
● Available | Contact us for lead time and pricing
| SKU | PES-SPS-SOL-2362 |
|---|---|
| Manufacturer | PES Supply |
| Container price | |
| Container qty | |
| Odoo id | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer |
No documents available for this product. Contact us to request documentation.
