SimpliPhi BOSS-6-COMB-2000 Battery Combiner (2000A, Outdoor-Rated)
The BOSS-6-COMB-2000 integrates high-capacity busbars and distribution inside a NEMA 3R carbon-steel enclosure, enabling clean, safe parallel connection of up to six SimpliPhi PHI batteries.
| Manufacturer | Briggs & Stratton Energy Solutions (SimpliPhi) |
|---|---|
| MPN | BOSS-6-COMB-2000 |
| Enclosure Rating | NEMA 3R, outdoor-rated carbon steel; corrosion-resistant fan |
| Capacity (battery count) | Up to 6 PHI LFP batteries |
| Main Busbars | Tinned copper busbars, 2000A rating; approx. 5" wide × 20" tall × 0.5" thick, 3/8" clearance holes |
| Built-in DC Connections | 2 × 5-point terminal busbars, 3/8" lugs, 650 ADC |
| Operating Temp (charge) | 32 °F to 120 °F |
| Dimensions (W × H × D) | 36" × 36" (40" with feet) × 16" |
| Weight | ~180 lb (without batteries) |
| Mounting | Free-standing or pad-mounted; side knockouts (3 × 1" trade size per side) |
| Warranty | Enclosure: 2–5 years (per retailer/manufacturer program; confirm on purchase) |
| References | Manufacturer drawing (2000A busbar & dimensions); BOSS cabinet spec sheet; A1 SolarStore & InverterSupply listings |
References: Manufacturer drawing and BOSS sell sheet for ratings & dimensions; retailer listings for weight, dims and pricing.
