Alpex Solar ALP 160W Polycrystalline Monofacial Solar Panel
ALP 160W | Polycrystalline | 36 Cells Poly | Monofacial | 600V System Voltage
Product Overview
The Alpex Solar ALP 160W Polycrystalline Monofacial Solar Panel delivers reliable energy for diverse applications. This robust module features 36 high-quality polycrystalline silicon cells arranged in a 4x9 grid. It generates a maximum power output of 160 Watts under standard test conditions. The panel achieves an impressive module efficiency of 15.5 percent, optimizing space usage effectively. Its sturdy construction includes an anodized aluminum frame and tempered glass with an anti-reflection coating. This design ensures durability against snow loads of 5400 Pa and wind loads of 2400 Pa. The junction box is IP67 rated, providing excellent protection against dust and water ingress. Operating temperatures range from -40°C to +85°C, making it suitable for extreme climates. The panel weighs only 11 kg, facilitating easy installation on various mounting structures. It comes with 4 mm² cables and MC4 compatible connectors for secure electrical connections. This solar panel is an ideal choice for residential and small commercial power systems.
Key Benefits
High Durability: The panel withstands heavy snow loads of 5400 Pa and strong wind loads of 2400 Pa.
Weather Resistance: An IP67 rated junction box protects internal components from dust and water damage effectively.
Wide Temperature Range: It operates efficiently in temperatures ranging from -40°C up to +85°C without performance loss.
Optimized Efficiency: Anti-reflection coating on tempered glass maximizes light absorption and boosts energy generation output.
Long Warranty Life: Manufacturers guarantee 90% power output at year 10 and 80% output at year 25.
How It Works
This polycrystalline solar panel converts sunlight into usable electricity through the photovoltaic effect. Sunlight particles strike the 36 silicon cells, exciting electrons within the semiconductor material. These excited electrons flow through an internal circuit, generating direct current electricity. The anodized aluminum frame holds the cells securely while protecting edges from physical damage. The tempered glass cover shields the cells from environmental hazards while allowing maximum light transmission. Two bypass diodes inside the junction box prevent power loss if part of the panel is shaded. The MC4 connectors ensure a safe and weather-tight connection to the rest of the electrical system. This process continues as long as sunlight is available, providing a steady power supply.
Photovoltaic Conversion: Sunlight photons hit the silicon cells and release electrons to create an electrical current flow.
Current Protection: Bypass diodes allow current to flow around shaded cells, preventing total system power loss.
Energy Transmission: Generated electricity travels through 4 mm² cables to MC4 connectors for safe external connection.
Technical Specifications
| Type | Polycrystalline |
| Model Number | ALP 160W |
| Maximum Power (Pmax) | 160 Wp |
| Voltage at Max Power (Vmpp) | 18.3 V |
| Current at Max Power (Impp) | 8.74 A |
| Open Circuit Voltage (Voc) | 22.42 V |
| Short Circuit Current (Isc) | 9.42 A |
| Module Efficiency | 15.5 % |
| Power Range | 150 ~ 170 Wp |
| Efficiency Range | 14.52 ~ 16.46 % |
| Cell Number | 36 |
| Dimensions (H/W/D) | 1505 x 686 x 35 mm |
| Weight | 11 kg |
| Glass Type | Tempered with Anti-reflection Coating |
| Frame Type | Anodized Aluminium |
| Junction Box Rating | IP 67 |
| Bypass Diodes | 2 |
| Connector Type | MC4 |
| Cable Crossection | 4 mm² |
| Cable Length | 1000 mm |
| Encapsulant Type | EVA (Ethylene Vinyl Acetate) |
| Maximum System Voltage | 600 V |
| Series Fuse Rating | 10 A |
| NOCT | 45 ± 2 °C |
| Operating Temp Range | -40 to +85 °C |
| Temp Coeff of Pmax | -0.35 %/°C |
| Temp Coeff of Voc | -0.31 %/°C |
| Temp Coeff of Isc | 0.06 %/°C |
| Total Degradation Rate | 0.8 % |
Certifications & Compliance
Certifications: IEC 61215 Ed2, IEC 61730, IEC 61701, IEC 62716, IEC 62804, UL 61730, BIS
Inverter Compatibility: Compatible with all standard solar inverters operating within 600V DC limits
Environmental: Class A Safety Class II, RoHS compliant for environmental safety
Warranty: 90% power output at end of 10 Years, 80% power output at end of 25 Years
