Alpex Solar ALP 150W Polycrystalline Monofacial Solar Panel
Model ALP 150W | Polycrystalline | 36 Cells Monofacial | Monofacial | 600V System Voltage
Product Overview
The Alpex Solar ALP 150W Polycrystalline Monofacial Solar Panel is a reliable energy solution for small to medium installations. This polycrystalline solar panel delivers 150 watts of power with a module efficiency of 14.52 percent. It features 36 durable polycrystalline cells encased in anti-reflection tempered glass. The robust anodized aluminum frame ensures long-term structural integrity in harsh weather conditions. Designed for versatility, it operates efficiently between -40°C and 85°C. Its compact dimensions of 1505x686x35 mm make it ideal for limited spaces. The panel includes an IP67-rated junction box with two bypass diodes for safety. With a weight of only 11 kg, installation is straightforward and manageable. This model supports a maximum system voltage of 600 volts for grid compatibility. It is manufactured by Alpex Solar Limited in India with strict quality controls. The polycrystalline technology offers excellent performance in low-light environments. Users benefit from a 10-year warranty covering 90 percent power output. A 25-year warranty guarantees 80 percent longevity for decades of service. This solar panel combines affordability with proven durability for residential use.
Key Benefits
High Durability: The anti-reflection tempered glass resists scratches and impacts effectively.
Weather Resilience: It operates safely in temperatures ranging from -40°C to 85°C.
Long-Term Warranty: Users receive 10 years at 90 percent and 25 years at 80 percent output.
Lightweight Design: Its 11 kg weight simplifies mounting on roofs or ground structures easily.
Safety Protection: The IP67 junction box with bypass diodes prevents electrical overheating risks.
How It Works
The Alpex Solar ALP 150W panel converts sunlight into usable electricity through photovoltaic action. Polycrystalline silicon cells absorb solar photons and release electrons to create current flow. This direct current is then managed by the junction box for safe system integration. The bypass diodes prevent power loss if some cells are shaded or obstructed. Temperature coefficients ensure stable performance even as ambient heat fluctuates daily. The EVA encapsulant protects internal cells from moisture and mechanical stress. Anti-reflection coating maximizes light absorption by reducing surface reflection losses. This process ensures consistent energy generation throughout the day and year. The anodized frame provides structural support against wind and snow loads effectively. Overall, the system delivers reliable power for homes and small commercial needs.
Photovoltaic Conversion: Sunlight hits the 36 polycrystalline cells to generate direct current electricity. Electrons move freely within the silicon lattice to create a flow of energy.
Current Management: The junction box collects the generated current and routes it safely to the output cables. Bypass diodes activate to prevent reverse current flow during partial shading events.
Environmental Adaptation: Temperature coefficients adjust voltage and current output based on ambient heat levels. The tempered glass and EVA layer shield cells from extreme weather damage.
Technical Specifications
| Technology Type | Polycrystalline |
| Model Number | ALP 150W |
| Maximum Power (Pmax) | 150 Wp |
| Module Efficiency | 14.52% |
| Cell Count | 36 Polycrystalline Cells |
| Voltage at Max Power (Vmpp) | 17.83 V |
| Current at Max Power (Impp) | 8.42 A |
| Open Circuit Voltage (Voc) | 21.9 V |
| Short Circuit Current (Isc) | 9.15 A |
| Maximum System Voltage | 600 V |
| Dimensions (L x W x H) | 1505 x 686 x 35 mm |
| Weight | 11 kg |
| Frame Material | Anodized Aluminium |
| Glass Type | Tempered with Anti-reflection Coating |
| Junction Box Rating | IP 67 |
| Bypass Diodes | 2 Diodes |
| Connector Type | MC4 Compatible |
| Cable Cross Section | 4 mm² |
| Cable Length | 1000 mm |
| Encapsulant Type | EVA (Ethylene Vinyl Acetate) |
| Temperature Range | -40°C to +85°C |
| NOCT | 45 ± 2°C |
| Temp Coeff of Pmax | -0.35%/°C |
| Temp Coeff of Voc | -0.31%/°C |
| Temp Coeff of Isc | 0.06%/°C |
| Max Series Fuse Rating | 10 A |
| Total Degradation Rate | 0.8% Maximum |
Certifications & Compliance
Certifications: IEC 61215 Ed2, IEC 61730, IEC 61701, IEC 62716, IEC 62804, UL 61730, BIS
Inverter Compatibility: Compatible with standard inverters supporting 600V DC input
Environmental: ISO 9001:2015, ISO 14001:2015, ISO 45001:2018 Certified Manufacturing
Warranty: 10 Years at 90% Power Output, 25 Years at 80% Power Output
