Solectria PVI 50TL/60TL
The Solectria Fuse Bypass Kit for PVI 50TL/60TL inverters is a versatile solution designed to enhance the performance and adaptability of commercial solar installations. These inverters are specifically crafted to be compact and transformerless, providing superior efficiency and compatibility for diverse settings such as rooftops, carports, and ground-mount systems.
Product Features
Transformerless Design
The transformerless PVI 50TL/60TL inverters offer enhanced energy conversion efficiency, making them ideal for a range of solar installation scenarios while maintaining compact profiles and lightweight structures.
Dual-Rating Capability
These inverters feature a dual-rating capability, allowing users to choose between 50/60 kVA and 55/66 kVA, thus enabling flexible power delivery and accommodating varying photovoltaic system demands.
Advanced Safety Compliance
Outfitted with built-in SunSpec compliant transmitters, the kit ensures module-level rapid shutdown, offering safe and straightforward NEC compliance for installers.
Integrated Arc-Fault Protection
To enhance safety, the kit includes integrated UL-listed arc-fault protection, contributing to reliable operation and reducing the risk of electrical faults.
Versatile Mounting Options
The units support a wide range of mounting angles, from 15° to 90°, allowing for easy installation on various structures, including rooftops, without compromising performance.
How It Works
The fuse bypass kit operates seamlessly by integrating with the PVI 50TL/60TL inverter systems, enhancing their capacity to manage power while complying with safety standards. This system incorporates key components that ensure efficient and safe operation.
SunSpec Compliant Transmitter
This component ensures module-level rapid shutdown compliance, facilitating adherence to safety regulations with minimal effort.
AC/DC Disconnects
Equipped with standard integrated AC and DC disconnects, the system provides easy access for maintenance and ensures user safety during operations.
Remote Capabilities
The kit supports remote firmware upgrades and diagnostics, allowing for real-time monitoring and management, thereby enhancing operational efficiency and convenience.
Specifications
| Maximum PV Power | 90 kW (33 kW per MPPT) |
| Maximum Input Voltage | 1000 VDC |
| Number of MPPT Trackers | 3 Trackers |
| Rated AC Real Power | 50 kW / 60 kW |
| Nominal Output Frequency | 60 Hz / 57-63 Hz |
| Peak Efficiency | 98.8% |
| Total Harmonic Distortion (THD) | < 3% |
| Grid Connection Type | 3-Ph/PE/N |
| Enclosure Rating | NEMA Type 4X |
| Weight | Inverter: 123.5 lbs; Wiring Box: 33 lbs |
| SKU | PES-PA-ELC-0016 |
|---|---|
| MPN | PVI 50TL/60TL |
| Manufacturer | Solectria |
| Brands | |
| Compliance special features | |
| Container price | |
| Container qty | |
| Documents | |
| Pallet price | |
| Unit price | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
