Growatt SYN 200-XH-US-11A Whole Home Backup ATS – 200A Breaker + Smart Meter
Growatt SYN 200-XH-US-11A Whole Home Backup ATS – 200A Breaker + Smart Meter
PayPal Pay in 4 interest-free payments of $305.25 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Your card is not charged until stock is confirmed. Enter your ZIP below for a transit estimate. Tracking provided once your order ships.
Ships via ground carrier, tracked. Pallet & heavy orders go LTL freight — our team confirms freight within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PV06.0005500
Complete the job
Verified compatible gear for this system
PES Supply is an authorized distributor for Growatt. 50,000+ SKUs from 169 authorized brands.
The Growatt SYN 200-XH-US-11A is the 200A whole-home automatic transfer switch for MIN TL-XH-US V3 inverters, with integrated SM-US smart meter and sub-0.5s switchover.
Key Features
- 200A automatic transfer switch for whole-home backup (<0.5s switchover)
- Integrated SM-US smart meter
- Built-in split-phase transformer for 120/240V output; NEMA 4X outdoor rated
- Remote wake-up and control; 10-year warranty
- For generator port, see SYN 200-XH-US-13A
Compatibility: Growatt MIN TL-XH-US V3 inverters (whole home backup); ARO/APX & LG Prime/Enblock batteries
Specifications
| Model | SYN 200-XH-US-11A |
| Part Number | PV06.0005500 |
| Rating | 200A, 120/240V split-phase |
| Switchover | <0.5 s on/off-grid |
| Smart Meter | Integrated SM-US |
| Generator Port | No (see 13A) |
| Enclosure | NEMA 4X |
| Certifications | UL1741, CSA 22.2 No.107.1, UL869A, FCC Part 15 |
